Features

• ➤ In conformity with the soil conditions it is being produced with 2, 3, 4 & 5 bottom versions.
• ➤ It is directly mounted to the tractors.
• ➤ Extra Heavy-duty pipe frame has high trash clearance allowing the plough to operate under heavy crop residue.
• ➤ It is used to open new fields and process stony areas.
• ➤ It can be used easily at rocky and rooted areas.
• ➤ Especially useful in hard and dry trashy land conditions and in soils where scouring is a major problem.
• ➤ High-quality bearings and hubs ensure smooth operation and put minimum load on the tractor.
• ➤ High-quality seals prevent the entry of mud and water into the bearings and hubs.

Technical Specifications:

DESCRIPTION	CUL-BD5	CUL-BD7	CUL-BD9	CUL-MD5
Tynes	5	7	9	5
Working Width (Inch)	69	94	120	60
Mainframe Size (Pipe mm)	72*72*6	72*72*6	72*72*6	50*50*5
Tyne Thickness (mm)	32	32	32	25
Soil Opener	Duck Foot	Duck Foot	Duck Foot	Duck Foot
Weight (Kg) (Approx.)	225	315	380	120
